TI-GEAR-M325 | 25mm | 384x288 | 50Hz | 17µ
[Code: TIG325.M]

TI-GEAR-M325 | 25mm | 384x288 | 50Hz | 17µ
TI-GEAR-M325 | 25mm | 384x288 | 50Hz | 17µ

Click here to get a quote

The TI-GEAR-M325 is the professional-grade thermal monocular designed for multiple applications that involve reconnaissance and tactical surveillance at short-and medium-range distances.The latest generation silent and Auto-NUC sensor is at the base of the TI-GEAR-M325. GSCI proprietary hardware and software solutions are built around the sensor and offer exceptional image quality along with unique tools for added tactical advantage and user safety.Apart from hand-held, helmet-mounted configurations, the TI-GEAR-M325 can easily be converted into a full-feature thermal weapon and clip-on sight. The TI-GEAR-M325 is fully dust-and waterproof, meets and exceeds modern standards. The TI-GEAR-M325 is designed for both professional users andoutdoor enthusiasts. It is a robust, reliable tool for long-term, intensive use in any environment, in any lighting or weather conditions.

Specifications
TI-GEAR-M325
Optical Magnification
1.5X
Objective Lens Focal Length
25mm
Field of View
14.9°x11.2°
Focusing Range
0.5m .. Infinity
Eyerelief
Min. 40mm
FPA Resolution and Pitch
384x288, 17μm
FPA Type
Uncooled, a-Si, Shutterless, Silent, Auto-NUC (Uninterrupted Operation)
FPA Sensitivity
<50mK
FPA Refresh Rate
50Hz
Digital Zoom
1X, 2X, 4X
Display
Full Size: 0.6-Inch Diagonal, AMOLED, Colour, 800x600
Imaging Modes
Monochrome (White-Hot / Black-Hot)
and 8 Colour Palettes
Shot-Initiated FOV Feature (SIF)
Optional: Built-In Adjustable Shock Sensor
Digital Passive Stadiametric Rangefinder (SRF)
Yes
Digital Detail Enhancement Feature (DDE)
Yes
Wide Dynamic Range Feature (WDR)
Yes
Stow Safety Feature (SSF)
Yes
Integrated 9-Axis Absolute Orientation HUD
(Heads-Up Display)
Optional:3-Axis Sensors -Magnetometer,
Accelerometer and Gyroscope
Integrated Compass
Optional
Pitch / Roll / Azimuth Indications
Optional
Real-Time Date-Time Stamp
Yes: Simplified, Extended, DTG Formats
Digital Video Recorder
Optional: Built-In with microSD Card
or External with SD Card
Electronic Reticles
Optional: 8+8 Patterns, Easy Zeroing / Calibration
Max. Detection Human (1.7x0.5m)
830m
Max. Detection Vehicle (2.3x2.3m)
1130m
Hand-Held Capability
Yes: Hand-Held + Helmet-Mountable
Conversion to Clip-On (In-Line) Sight
Yes
Conversion to Standalone (Direct-View) Sight
Yes
Tripod-Mountable
Yes
User Profiles (Configurable)
Yes: 8
Automatic/Manual Pixel Masking
Yes
Reset to Factory Defaults
Yes
External Video Feed Protection
Yes
Automatic Power Down Control
User-Configurable: 10 .. 60 minutes
of inactivity
Universal Port
Video-Out, Remote Control and External
Power (4VDC .. 15VDC)
Accepted Batteries
2 (two) CR123 of Any Type: Lithium / Rechargeable
Battery Life
Up to 7
Environmental Protection
Min. IP67, Nitrogen-Purged Housing
Dimensions
140 x 60 x 60 mm
Weight
365 grams
Operating Temperature
-40C .. +50C


INCLUDED ACCESSORIES
1 Thermal Imaging Monocular
2 Rubber Eyecups (Installed on the device)
3 Protective Lens Cover (Installed on the device)
4 USB Power Cable
5 Video-Out Cable
6 Soft Carrying Pouch
7 User Manual
8 Quick Reference Card
9 7-Year Warranty with Activation Form
10 Waterproof Hard Carrying Case
11 Cleaning Kit (3-in-1 Multi-Pen + Cleaning Cloth)

OPTIONAL EQUIPMENT
A Advanced Helmet Mount Harness HMH-1
B Universal Remote Control Unit TRC-120 (Comes with connection cable)
C Universal Multi-Voltage Battery PackMVP-240 (Comes with connection cable)
D Built-In Digital Video Recorder GS-DVR-INT (Comes with 32GB microSD card and SD adapter)
E External Digital Video Recorder GS-EDVR (Comes with set of cables and 32GB SD card)
F Portable Head-Mounted Display HMD-800-MOD (streams thermal video directly from the device, comes with connection cable)
G Integrated 9-Axis Absolute Orientation HUD (Heads-Up Display), 3-Axis Sensors for Compass Reading, Inclinometer/Pitch Reading, and Level/Roll Reading
H AdjustableDual Quick Release Weapon Mount DQRM (Picatinny, with fine-tune knobs for tolerance adjustments)
I Dual Lever Adjustable Rifle Mount DLM (Picatinny, with fine-tune knobs for tolerance adjustments)
J Heavy-Duty Quick Release Rifle Mount MAK-QR-BLASER (Blaser, Adapter included)
K Heavy-Duty Quick Release Rifle Mount MAK-QR-PICATINNY (PICATINNY, Adapter included)
L Heavy-Duty Rifle Mount MAK-PICATINNY (PICATINNY, Adapter included, Allen Key Included)
M Adapter for MAK Mount: Regular Length (ADAPTER-REG) or Extended Length (ADAPTER-EXT)
N Clip-On Adapter COA
O Day Scope Adapter Clamp for COA for direct mounting onto daytime optics, CO-DSA (various sizes available)
P Long Eyerelief Rubber Eyecup GSCI-EYECUP-LR
