PVS-31C-MOD | ECHO | FOM 2000 | AG-MGC | White Phosphor
[Code: 31M.EC.45]
The PVS-31C-MOD is a dual-tube goggle system with ergonomic design and improved functionality. It accommodates features such as a dedicated Instant-On-IR button to quickly and momentarily engage IR illuminator without having to operate the switch. The connector located at the front of the unit is used to supply power to the unit from almost any power source: external battery pack, USB power bank, 12V car socket and so on. By customer's request, the unit can be equipped with Bayonet (PVS) or Dove-Tail style bracket.
Universal Night Operations Tool
Unique Safety Features
Extended Range Observation
High Situational Awareness
Accepts External Power Sources
Preferred choice of NATO forces
| Lens System |
27mm. f/1.2
|
| Diopter Adjustment Range |
-6 ... +2
|
| Optical Magnification |
1X
|
| Field Of View (FOV)* |
40°
|
| Interpupillary Adjustment Range |
50mm ... 90mm
|
| IIT |
ECHO
|
| Autogated |
Yes
|
| Manual Gain Control |
Yes
|
| IR Illuminator |
Yes: Built-in
|
| Instant IR-On Button |
Yes
|
| Bright Light Sensor |
Yes: Built-In
|
| IR LED Indicator |
Yes
|
| Bright Light LED Indicator |
Yes
|
| Low Battery LED Indicator |
Yes
|
| Stow Safety Feature |
Yes
|
| Selective Channel Engagement Feature |
Yes
|
| Flip-Up-Off Feature |
Yes
|
| External Power Port |
Yes
|
| Power Source |
1x AA, 1x CR123 or MVP-240
|
| Battery Life (AA / CR123) |
40 Hours
|
| Battery Life on MVP-240 |
240 Hours
|
| Environmental Protection |
Waterproof
|
| Operating Temperature |
-40°C .. +50°C
|
| Dimensions |
108 x 105 x 70 mm
|
| Weight |
465 grams
|
| Warranty |
7 Years, Limited
|
STANDARD EQUIPMENT
Dual-Tube Night Vision Goggles with Bayonet or Dovetail Bracket (Installed on the Device)
Rubber Eyecups (2pcs,Installed on the Device)
Sacrificial Window (2pcs) + 2pcs Free
Stow Safety Feature (Integrated)
AA Battery Extension Adapter (Installed on the Device)
Rubber Daytime Filter with Training Hole (Installed on the Device)
Adjustment Kit (Allen Key + Mini-Wrench)
USB Power Cable
Neck Cord
Soft Carrying Pouch
User Manual
Cleaning Kit (3-in-1 Multi-Pen + Cleaning Cloth
