3-12x50 LP | CW | DT-ST | P3L Reticle
[Code: 644.88294A38]
The superior optical and mechanical performance of the 3-12x50 PM II makes it perfect for engaging targets up to medium distances in any kind of environment. This and the exceptional reliability of this riflescope have been proven many times around the globe. The success expressed by the USMC contract reflects the high esteem of the top quality level which Schmidt & Bender uncompromisingly aims for – until this very day.
| Magnification |
3–12
|
| Exit pupil-Ø (mm) |
14.3–4.3
|
| Field-of-view (m/100 m) |
11.1–3.4
|
| Length (mm) |
342
|
| Weight (g) |
860
|
| Mount system |
Ring mount
|
| Main tube-Ø (mm) |
34
|
| Parallax adjustment (m) |
50 to ∞
|
| Reticles |
P3L
|
| Focal Plane |
1
|
| Illumination |
11 settings
|
| Turrets (Elevation /Windage) |
DT / ST
|
| Turret rotation |
cw/ccw
|
| Click value |
0.1 MRAD
|
| Adjustment range elevation |
23 MRAD
|
| Adjustment range windage |
± 6 MRAD
|
| Internal travel elevation |
26.6 MRAD
|
| Internal travel windage |
24 MRAD
|
