GNG | GO/ NO-GO for NVD
[Code: TR.GNG]
Operated using a single 1.5V battery, the Go/ No Go (GNG) Field Test Station promptly tests operative readiness where the users are located far from a working laboratory. The GNG is handheld, very lightweight, and fits various types of NVDs. It essentially gives the operator the “go ahead” when using his regularly issued NVD without having to wait for a technician to arrive, or having to use higher-grade equipment. The GNG could also be attached to the wall in a readiness room, so the user can just plug his NVD into it, switch it on, and see the result within a few seconds.The GNG is fitted for most existing NVD models, and could be custom fitted for more upon demand.
Features
Test both Gen. II & Gen. III Tube
Laboratory and Field Grade
Autonomous and Portable
Battery and Electrically Operated
Suitable for Various Types of NVDs
Mil-Std Compliance
Light source |
IR LED 810 nm (±30) and white LED
|
Light levels |
Low |
Approximately equivalent to illuminant level of the moonless overcast night sky.
|
High |
Approximately equivalent to illuminant level of the quarter moon sky condition.
|
200 Lux |
Equivalent to illuminant level of day light
|
Resolution target |
Standard USAF 1951
|
Dimensions |
|
Power source |
1 Alkaline 1.5V Battery or 110/220V
|
Operating Temperature |
-10°C to +50°C
|
Weight |
|
