LAM-3G | Visible and I/R | 2000m
[Code: NC.3GR]

LAM-3G | Visible and I/R | 2000m
LAM-3G | Visible and I/R | 2000m LAM-3G | Visible and I/R | 2000m

Click here to get a quote

The LAM 3G is a multi-laser aiming system equipped with collimated visible and IR lasers designed to reach out to 2,000m. Built-in IR illuminator and IR aiming laser provide covert tactical precision when paired with night vision devices. Features an adjustable IR illuminator for better illumination at longer ranges, dual activation switches and high/low power modes ensures appropriate laser intensity during training exercises. With a quick-release M1913 mount, the LAM 3G is among the lightest aimers in its class and is the right choice for professional operators demanding unrivaled performance and reliability. The unit is constructed of high-strength aluminum and can withstand rigors of tactical life on virtually any weapon platform.


Laser Aimer
LAM 3G
Eye safety
IIIb
Distance, high / low (m)*
V:150/500 ; IR: 200/2,000
Beam divergence, FWHM (mrad)
0,5
Spot size @ 100m (mm)
50
Wavelength (nm)
V:532 ±10 / IR: 830 ±15
Infrared Laser Illuminator
Eye safety
IIIb
Distance, high / low (m)
V:150/500 ; IR: 200/2,000
Beam divergence, FWHM (mrad)
1 - 105
Spot size @ 100m, min divergence /
max divergence (cm)
5
Wavelength (nm)
V:532 ±10 / IR: 830 ±15
Ballistics
Windage adjustment step (mrad)
0.5
Windage adjustment range (mrad)
40
Elevation adjustment step (mrad)
0.5
Elevation adjustment range (mrad)
40
Retention after 1,000 shots (mrad)
1
Mechanics, Electronics & Environmental
Dimensions (mm)
100x73x41
Weight without batteries (g)
300
Shock resistance (G)
300
Quick release
Yes
Battery type
CR 123
Battery life, high / low (hours)
8 / 16
Operating temperature range (°C)
-10 to +50
Storage temperature range (°C)
-40 to +60
Waterproofing
IP67


WARNING! These laser module emits radiations that is invisible and harmful to human eye.



Price: 0,00 €
