Hawkeye Laser Aimer | Visible and I/R | 1000m
[Code: LA.HAWYE]
The HAWKEYE makes for accurate aiming, target acquisition and marking, ground-to-ground and ground-to-air signaling and much more. The HAWKEYE is fitted for use with standard Night Vision Devices, and standard mounting platforms.
| Beam Shape |
Dot
|
| Beam Divergence |
0.3 mRad max
|
| IR Wavelength |
850nm
|
| Red Wavelenght |
635nm
|
| Radiation Mode |
PTL Cable
|
| Output Power (High) |
<5mV
|
| Eye Safety (High) |
<5mV
|
| Boresight Adjustment Travel Range |
<3.5° (Elevation and Deflection)
|
| Travel Increment Size (no tools needed) |
0.3mRad (discrete increment- click)
|
| Power Source |
Single 1.5V AA Battery
|
| Continous Work (High) |
30 Hrs.
|
| Rifle Mounting |
MIL-STD-1913 (Picatinny)
|
| Designation Range (Low Power Mode) |
>650m (depending on visibility)
|
| Designation Range (High Power Mode) |
>950m
|
| Operating Switch |
3 Modes Switch
|
| Dimensions (L x H x W), Net |
108 X 33 X 60mm
|
|
Dimensions (L x H x W),
with Picatinny Adaptor |
108 X 43 X 60mm
|
| Weight, net |
<210gr.
|
| Weight, with Picatinny Adaptor and Battery |
255gr.
|
| Life Time |
>10,000 hrs.
|
INCLUDED ACCESSORIES
Carrying Case
Remote Control
Remote Control
Battery
Operation Manual
Microfiber Cleaning Cloth
Safety CordWARNING! These laser module emits radiations that is invisible and harmful to human eye.
Ask information about Hawkeye Laser Aimer | Visible and I/R | 1000m
