Beam Shape |
Dot
|
Beam Divergence |
0.3 mRad max
|
IR Wavelength |
850nm
|
Red Wavelenght |
635nm
|
Radiation Mode |
PTL Cable
|
Output Power (High) |
<5mV
|
Eye Safety (High) |
<5mV
|
Boresight Adjustment Travel Range |
<3.5° (Elevation and Deflection)
|
Travel Increment Size (no tools needed) |
0.3mRad (discrete increment- click)
|
Power Source |
Single 1.5V AA Battery
|
Continous Work (High) |
30 Hrs.
|
Rifle Mounting |
MIL-STD-1913 (Picatinny)
|
Designation Range (Low Power Mode) |
>650m (depending on visibility)
|
Designation Range (High Power Mode) |
>950m
|
Operating Switch |
3 Modes Switch
|
Dimensions (L x H x W), Net |
108 X 33 X 60mm
|
Dimensions (L x H x W),
with Picatinny Adaptor |
108 X 43 X 60mm
|
Weight, net |
<210gr.
|
Weight, with Picatinny Adaptor and Battery |
255gr.
|
Life Time |
>10,000 hrs.
|
